Product Description
3/8" Dia., 4 Flute, YG-1 X5070 High Feed Carbide End Mill, Blue Coated
- Excellent wear resistance at heavy feed rates on high hardened material.
- Designed with reduced clearance angles and short flutes for strength.
- High hardness & heat resistance coating for long life in dry applications.
- Solid Carbide
| Specs | ||
| D1 | Diameter | 3/8 in. |
| D2 | Shank Diameter | 3/8 in. |
| D3 | Neck Diameter | 0.33 in. |
| L1 | Length of Cut | 0.15 in |
| L2 | Overall Length | 2-3/4 in. |
| L3 | Length Below Shank | 3/4 in. |
| Flutes | 4 | |
| Corner Radius | 3/32 in. | |
| Coating | Blue Coated | |
Product Videos
Custom Field
Diameter 3/8 in.
Length of Cut .15 in.
Overall Length 2-3/4 in.
Flutes 4 Flutes
Coating Blue Coated
End Type Corner Radius 0.094 in.
Type High Feed
