Product Description
M14 x 2 D7 3 Flute Spiral Fluted Combo Tap, Coolant Thru, Multi-Purpose TiN Coated HSS-EX
MULTIPURPOSE TAPPING IN VARIOUS DUCTILE MATERIALS
Combo Tap's geometry is designed to provide smooth chip evacuation resulting in uninterrupted manufacturing. Guaranteed process reliability even in less rigid machining conditions.
- For Steels, Stainless Steels, Cast Iron and Non-Ferrous Materials
- Prevents over & under feeding by its optimized flank geometry
- Constant threading quality preventing oversized threading
| Specs | ||
| OD | Thread Size | M14 x 2 |
| Od | Shank Diameter | 0.429" |
| Lt | Thread Length | 0.709" |
| L | Overall Length | 3.59" |
| K | Square Size | 0.322" |
| kl | Square Length | 0.500" |
| Flutes | 3 | |
| Limit | D7 | |
| Chamfer | 2P-3P | |
| Coating | TiN | |
Product Videos
Custom Field
Diameter M14 x 2
Length of Cut 0.709 in.
Overall Length 3.59 in.
Flutes 3 Flutes
Coating TiN
End Type Spiral Flute
Type Metric
Features D7 Limit
