Product Description
M24 x 3.0 D8 4 Flute Spiral Fluted Combo Tap, Short Chamfer, Multi-Purpose TiCN Coated HSS-EX
MULTIPURPOSE TAPPING IN VARIOUS DUCTILE MATERIALS
Combo Tap's geometry is designed to provide smooth chip evacuation resulting in uninterrupted manufacturing. Guaranteed process reliability even in less rigid machining conditions.
- For Steels, Stainless Steels, Cast Iron and Non-Ferrous Materials
- Prevents over & under feeding by its optimized flank geometry
- Constant threading quality preventing oversized threading
| Specs | ||
| OD | Thread Size | M24 x 3.0 |
| Od | Shank Diameter | 0.760" |
| Lt | Thread Length | 0.945" |
| L | Overall Length | 4.906" |
| K | Square Size | 0.570" |
| kl | Square Length | 0.750" |
| Flutes | 4 | |
| Limit | D8 | |
| Chamfer | 1P-2P | |
| Coating | TiCN | |
Product Videos
Custom Field
Diameter M24 x 3.0
Length of Cut 0.945 in.
Overall Length 4.906 in.
Flutes 4 Flutes, Short Chamfer
Coating TiCN
End Type Spiral Flute
Type Metric
Features D8 Limit
